Lockheed Martin F-35 Lightning II

2006
Lockheed Martin Lockheed Martin F-35 Lightning II 2006 - Front 3/4 viewLockheed Martin Lockheed Martin F-35 Lightning II 2006 - Front viewLockheed Martin Lockheed Martin F-35 Lightning II 2006 - Profile viewLockheed Martin Lockheed Martin F-35 Lightning II 2006 - Rear 3/4 viewLockheed Martin Lockheed Martin F-35 Lightning II 2006 - Rear viewLockheed Martin Lockheed Martin F-35 Lightning II 2006 - Cockpit viewLockheed Martin Lockheed Martin F-35 Lightning II 2006 - Cabin viewLockheed Martin Lockheed Martin F-35 Lightning II 2006 - Instrument Detail view
Front 3/4

Most ambitious and expensive weapons program in history, delivering stealth capability to allied nations worldwide.

History

The Joint Strike Fighter program aimed to replace multiple aging aircraft types across three services and allied nations with a single affordable stealth platform. The F-35 comes in three variants: the conventional F-35A, the short takeoff/vertical landing F-35B for Marines and allied carriers, and the carrier-capable F-35C for the US Navy. Its sensor suite and data fusion capabilities turn the aircraft into a flying sensor node that can share targeting data across the entire battlespace. Despite cost overruns and development delays, the F-35 has become the free world's standard fifth-generation fighter with over a dozen partner nations. The program represents the largest defense acquisition in history.

Production & Heritage

Production Total1,000
DesignerLockheed Martin team
Service Period2006

Technical Specifications

EnginePratt & Whitney F135-PW-100 turbofan
Max Speed1200 mph
Range1200 nm
Ceiling50,000 ft
Crew1
Wingspan35 ft
Length51.3 ft
Empty Weight29,300 lbs
Max Weight70,000 lbs

Engine Details

Engine ModelPratt & Whitney F135-PW-100
Engine Count1
Engine ManufacturerPratt & Whitney
Thrust43000 lbs

Performance

Cruise Speed650 mph

Dimensions

Wing Area460 sq ft

Weights

Max Takeoff Weight70,000 lbs

Armament

Guns1x 25mm GAU-22/A cannon
MissilesAIM-120 AMRAAM, AIM-9X Sidewinder, AGM-154 JSOW, AGM-158 JASSM
BombsGBU-31/32 JDAM, GBU-39 SDB, B61 nuclear

Capacity

Crew1

Tags

Designed by Lockheed Martin team
